InteliSENS® SL-i4
InteliSENS® SL-i4
SPEED & LENGTH MEASUREMENT
The InteliSENS® SL-i4 non-contact speed and length measurement gauge is ideal for flat surface products in “roll to roll” or “cut to length” processes. Paper, Film, Foil, Wovens, Non-Wovens, Textiles, Roofing, Sidings, Gypsum Board are just a few examples. Applications where speed measurement is critical for drive control or where length measurement is critical for product quality will benefit from the increased accuracy of Laser Doppler Speed and Length Measurement.
Focused on connectivity the SL-i4 Smart Sensor with 32bit communications comes preloaded with Profibus, Profinet and Ethernet Industrial Protocol for your PLC connection. Modbus, OPC-UA, RS232, RS485 and WiFi round out a wide range of digital communications for your Industry 4.0 Solution.
- No Moving Parts, Increased Reliability and MTBF
- Pulse outputs like your encoder
- Incredibly small and easy to install
- Stand Alone Measuring Device or Fully Integrated to PLC
- No Slip, No Wear, No Marking
- Industry 4.0 Data Communications
Performance
| SL 1525-i4 | SL 3060-i4 | SL 6060-i4 | |
| Stand Off Distance | 150mm 5.9” |
300mm 11.8” |
600mm 23.6” |
| Depth of Field | 25mm 1” |
60mm 2.4” |
60mm 2.4” |
| Minimum Speed | 0.2 m/min 0.66 ft/min |
0.3 m/min 1.0 ft/min |
0.3 m/min |
| Maximum Speed | 2000 m/min 6562 ft/min |
3000 m/min 9842 ft/min |
3000 m/min 9842 ft/min |
Accuracy
Factory Calibrated to better than 0.05% within the central 20% of the Depth of Field.
Repeatability of 0.02%
Measurement
Maximum Acceleration Rate of 1000m/s2 (3280ft/s2)
Measurement Rate Up to 25,000/sec
Units
Speed Measurement selectable m/min, ft/min, yd/min
Length Measurement selectable m, ft, inch, yd
Mode
Normal (Continuous Length), Batch Length
Object Detection
Automatic Detection and Object Present
Connectivity
6 Pulse Outputs
Default Output 5vdc or User Input to 24vdc
Max Maximum Frequency 1MHz Pulse Rate Selectable - Pulse/Meter or
Meter/Pulse Configurable as 6 x Single End or 3 Quadrature or 3 Differential.
Non Isolated from Gauge Head, Opto Isolated from the PSU-BOB i4
5 Logic Inputs
Maximum Input Voltage 24Vdc
2 x Fixed logic Inputs - Laser Enable and Shutter Enable
3 x Selectable logic Inputs - Reverse Direction, Length Reset, Display Hold, Speed Hold, Total Length Reset, End of Reel
4 Logic Outputs
Maximum Voltage 30Vdc, Current 100mA.
N-Channel MOSFET pull-down (for connection to user supplied onto isolated relay)
1 x Fixed Logic Output - Shutter Status
3 x Selectable logic outputs - Gauge Ok, Measuring Speed, Preset Length 1, Preset
Length 2, Good Readings Low, Object Detected, Gauge Hot.
2 Serial I/O
RS232 MODBUS RTU, PROTON ASCII code or Label Printer
USB using RS232 - USB Converter Cable
RS485 MODBUS RTU, PROTON ASCII code (Not available with PROFIBUS)
CANBUS
Connects to Proton Products CDi4 Display
Ethernet
Ethernet selectable between OPC-UA and Modbus
i-BUS
Connect to a PLC using PROFIBUS, PROFINET, or EtherNet I/P, data update rate up to 500/sec. Flexible Data Configuration, Big Endian, Little Endian
WiFi
Connect to a PC or Mobile Device using WiFi 2.4G and use the Proton Products Gauge App available for iOS and Android. Ideal for gauge configuration and diagnostics
Mobile App
1 Analogue Output
(Optional)
Speed, Good Reading
Laser Doppler
Class 3B Visible Laser.
Wavelength 650 - 670 nm, typically 658 nm with a beam diameter of 3mm (0.12”)
Total emitted power 40mW. Power Density at Stand Off Distance 50mW/cm2
Electrical and Operating Requirements
Power Supply
18 - 30 Vdc
Power Consumption
20 Watts
Operating Temerature
5c - 40c (41-104F)*
Environmental Protection
IP 67
Size and Weight
Height
220mm (8.7”)
Width
130mm (5.1”)
Thickness
78mm (3.1”)
Weight
3kg (6.6lbs)
Industry 4.0
 |
More than 200 Data Words are available to communicate with your Industry 4.0 Solution. Data Words are divided the into distinct function groups to make it easy to select the ones you want. |
| Gauge ID Data Words | Model Number, Serial Number, Firmware APP version, Firmware Core Version, Firmware Date |
| Calibration Data | Last Calibration Date, Days Since Last Calibration, Total Run Time, Calibration Alarm |
| Validation Data Words | SNR, Signal Amplitude, Good Readings, FFT Amplitude |
| Wired Network Info | IP Address, Netmask, Gateway |
| WiFi Network Info | IP Address, Netmask, Gateway, SSID |
| Measurement Data | Instant Speed, Average Speed, Batch Length, Total Length |
| Diagnostic Data | Laser Temperature, APD Temperature, Laser IN/OFF Cycles, Laser Power |
